Caniveau de drainage pour cour, terrasse et jardin

What is the length of each trench drain for yard?

All Vodaland trench drain yard channels are 1-meter (3.28ft) lengths. These patio drain channels can be connected together for longer runs of channel, and units can be cut to match specific sizing requirements.

Is the title width an internal or external dimension?

The width categories and all other width categories represent the internal width of the channel with grating, and the same applies to the depth sizes shown for each channel. External dimensions vary for each range of drainage channels, and customers can view external dimensions through the spec drawings provided on each product page.

How do I connect the trench drain for yard together?

We design all of our lawn channel drains to be connectable with each other via male-to-female connections. Depending on the model, your trench drain may either “click” together, or simply fit together for connection. It is very important that all connections are silicone sealed.

How do I connect piping?

For piping, Vodaland designs our channels with outlet options on the bottom, sides, and ends. These outlets can be attached to 4” Schedule 40 PVC pipe with an adapter we sell separately. If other piping is to be used, we recommend connecting them to the outlets via rubber couplings which are sold externally.

Do these need to be encased in concrete?

Vodaland recommends that all our channel drain for patio be encased in concrete for best reliability. Certain scenarios may not allow for the use of concrete, and in those cases customers may change the recommended installation method at their own discretion.

What are the max/min temperatures that the plastic channel drain for patio can handle?

Our plastic trench drain for backyard is suitable for temperatures between -40 to +45 degrees Celsius. Our installation method accounts for seasonal temperature changes through the use of expansion joints.

Do your trench drain channels have a slope?

Our trench for yard drainage is available in both no-slope and pre-sloped drain options to provide flexible solutions for all surface water management and yard drainage methods.

Why should I install a channel drain around patio or yard?

Having a channel drain along patio or yards is a great way to protect your property from water damage. Excess water from heavy rain or natural water runoff can pool in your yard or on your patio, and without a residential drainage solution, you run the risk of surface water seeping into your patio slab or basement wall. By installing a trench drain around patio you can collect all this water and direct it to a safer area. We supply a variety of designs and both wide and slim channel drains, so that it will also not look out of place in any domestic applications.
